I have made a project which is 100% pure 1Hz clock pulse using 4060 IC and crystal oscillator.This Circuit Works as pure 1Hz clock pulse. In the next video I’ll made 00 to 59 Counter , 00 to 11 Counter, 00 to 23 Counter.
we can generate this 1Hz clock pulse using 555 timer ic but the clock pulse of 555 timer ic is not 100% pure 1Hz clock pulse.that’s why I’ll use 4060 frequency divider IC and 32768Hz Crystal Oscillator.
If you like to see my video then Please SUBSCRIBE to my channel & Comment for more information about Electronics Project.
This circuit can be easily made at home. You can made it too. It take some component to make it which I used.
1. 4060 frequency divider IC ( 2 Pcs)
2. 32.768 KHz (32768Hz) Crystal Oscillator
3. 1 MegaOhm Resistor
4. 22pf Capacitor
5. Yellow LED (5mm)
6. 9 volt Battery
7. Some jumper Wire
8. Brade Board
Circuit Diagram : https://drive.google.com/file/d/1kPsegaTampPUDRO_JfP3jXiIXf7TzTlx/view?usp=sharing
